BMS Control Panel Design — Over 30 Years' Experience

Designs Built
on Reputation.
Proven in the Field.

From managing teams at the UK's most reputable panel builders to delivering bespoke BMS control panel designs nationwide — Excelsior brings industry-leading expertise to every project.

What We Offer

Services

With over thirty years of hands-on experience across the UK's most demanding BMS and controls projects, Excelsior Design delivers a comprehensive range of engineering drawing and consultancy services — with a clear understanding of the pace at which the modern building industry moves.

Provisional Design & Client Review

Every project begins with a thorough provisional draft design — developed from first principles and issued for client review before any build-stage detail is committed. This ensures alignment on scope, layout, and intent from the outset.

Full Build Package

Following client approval, drawings are developed to a complete build-ready standard — incorporating terminal references, wire numbering, and all associated documentation required for panel manufacture and site installation.

As-Built & Record Drawings

On completion of build and commissioning, drawings are updated to reflect the installed condition, providing accurate as-built records for the client and site archive — essential for future maintenance and compliance.

Retro-Fit & Drawing Modernisation

Existing panel drawings — however dated or incomplete — can be surveyed, redrawn, and brought up to current standards. Ideal for ageing plant where documentation has been lost or never formally produced.

Design Consultancy & Pricing Support

Independent consultancy services covering panel design strategy, specification review, and cost estimation. Whether supporting a tender submission or advising on a complex retrofit, we provide clear, experienced guidance.

Network Topology Schematics

Specialist production of BMS and controls network topology drawings — from large multi-storey, multi-network buildings through to straightforward FCU networks. Clarity and accuracy at every level of complexity.

Deadlines met. Standards maintained. Every time.

The construction and building services industry moves fast — programme pressures, last-minute design changes, and tight handover windows are the norm, not the exception. Excelsior Design operates with that reality at the forefront. Every project is managed with the urgency it demands, ensuring drawings are delivered on time and to the standard required for build — without compromise on quality. It is this commitment to both pace and precision that keeps Excelsior ahead of the competition.

Contact Us

Drop us a line!

[email protected]+44 7741 970482
